RESMED STELLAR 150 ASIA PAC G2

Description

The Stellar 150 by ResMed is a versatile ventilator designed for both non-invasive and invasive ventilation. This device is suitable for a wide range of patients, including adults and children, with varying respiratory needs. It is particularly beneficial for patients with conditions like chronic obstructive pulmonary disease (COPD), neuromuscular disease (NMD), and obesity hypoventilation syndrome (OHS).

Key Features of the Stellar 150:

• Therapy Modes: It offers multiple modes including iVAPS (intelligent Volume-Assured Pressure Support), ST (Spontaneous-Timed), PAC (Pressure Assisted Control), CPAP (Continuous Positive Airway Pressure), S (Spontaneous), and T (Timed).
• Pressure Range: The device can deliver Inspiratory Positive Airway Pressure (IPAP) between 2–40 cm H₂O and Expiratory Positive Airway Pressure (EPAP) between 2–25 cm H₂O.
• TiControl™: Allows for fine-tuning of the inspiratory time with Ti Max (0.3–4 seconds) and Ti Min (0.1–Ti Max).
• Respiratory Rate: Adjustable from 5 to 60 breaths per minute.
• Rise Time: Adjustable from 150 to 900 milliseconds.
• Alarms: Customizable alarms for high and low pressure, high leak, low minute ventilation, low and high respiratory rate, apnoea, low and high FiO₂, and low SpO₂.
• Dimensions and Weight: The device measures 230 x 170 x 120 mm and weighs 2.1 kg.
• Power Supply: Compatible with AC 100–240V 50–60Hz and DC 24V/3A, with an internal lithium-ion battery that provides up to 2 hours of operation at standard settings.
• Data Solutions: Includes ResScan and EasyCare Tx software for monitoring and managing patient data.
